Multiplatform Compose Animations

Multiplatform Compose Animations

Group of libraries to help you build better animations with Compose Multiplatform

Usage

kotlin {
    // Source set choice will depend on platform, but for commonMain
    sourceSets.commonMain.dependencies {
        implementation("co.touchlab.composeanimations:easing:1.0.1")
        implementation("co.touchlab.composeanimations:value-animator:1.0.1")
    }
}

About

Goal

The main goal of this project is to help you build animations with Compose Multiplatform. The Compose animations API provides a rich animation API to handle state changes, but some cases require to implement some boilerplate code.

What’s Included?

  1. Easings - A library with 30 different easings to control the speed of your animations
  2. Value Animator - API that provides you the same functionality from Android ValueAnimator, but using only compose methods

Why?

Compose animations are mainly focused on state changes. If you want to animate a value from X to Y, you need to:

  1. Create a state to control the state (and move from current to target)
  2. Use the animate function (which requires a coroutine scope and posting the value to some state);

Another limitation is when you have multiple values to animate through. In this case, there is no built-in solution to handle this case. Most APIs have similar syntax to Compose methods to make it more intuitive for you.

API

animate*AsState

Animate a value from X to Y and return the value as a state

  • animateFloatAsState
  • animateIntAsState
  • animateDpAsState
  • animateSizeAsState
  • animateOffsetAsState
  • animateRectAsState
  • animateIntOffsetAsState
  • animateIntSizeAsState
  • animateColorAsState

Signature:

@Composable
fun animateFloatAsState(
    initialValue: Float,
    targetValue: Float,
    startDelay: Long = 0,
    animationSpec: AnimationSpec<Float> = spring(),
): State<Float>

If you are using InfiniteTransition, compose already provide built-in methods for this.

animate*ValuesAsState

Animate through all values provided as arguments

  • animateFloatValuesAsState
  • animateIntValuesAsState
  • animateDpValuesAsState
  • animateSizeValuesAsState
  • animateOffsetValuesAsState
  • animateRectValuesAsState
  • animateIntOffsetValuesAsState
  • animateIntSizeValuesAsState
  • animateColorValuesAsState

Signature:

@Composable
fun animateFloatValuesAsState(
    vararg values: Float,
    startDelay: Long = 0,
    animationSpec: AnimationSpec<Float> = spring(),
): State<Float>

These methods are also available for InfiniteTransition. Signature:

@Composable
fun InfiniteTransition.animateFloatValues(
    vararg values: Float,
    animationSpec: InfiniteRepeatableSpec<Float> = infiniteRepeatable(animation = tween()),
    label: String = "MultipleFloatAnimation",
): State<Float>

ValueAtFraction

Interface to implement animation progress for unsupported types. It can be used on animateAsState and animateValuesAsState methods.

Signature:

fun interface ValueAtFraction<T> {
    operator fun invoke(
        fraction: Float,
        initialValue: T,
        finalValue: T,
    ): T
}

Example:

val floatAtFraction = ValueAtFraction<Float> { fraction, initialValue, finalValue ->
    initialValue + (finalValue - initialValue) * fraction
}

@Composable
fun AnimationTest() {
    val state by animateValuesAsState(
        values = floatArrayOf(0f, 1f, -1f, 4f),
        getValueAtFraction = floatAtFraction,
        startDelay = startDelay,
        animationSpec = animationSpec,
    )
}

The lib already provide a few implementations for types previously mentioned:

val ValueAtFraction.Companion.Float: ValueAtFraction<Float>
val ValueAtFraction.Companion.Int: ValueAtFraction<Int>
val ValueAtFraction.Companion.Dp: ValueAtFraction<Dp>
val ValueAtFraction.Companion.Size: ValueAtFraction<Size>
val ValueAtFraction.Companion.Offset: ValueAtFraction<Offset>
val ValueAtFraction.Companion.Rect: ValueAtFraction<Rect>
val ValueAtFraction.Companion.IntOffset: ValueAtFraction<IntOffset>
val ValueAtFraction.Companion.IntSize: ValueAtFraction<IntSize>
val ValueAtFraction.Companion.Color: ValueAtFraction<Color>

If you create custom types, you can also provide them as extensions from the ValueAtFraction companion.

Easings

The easing module contains 30 different easings to control the speed of your animations. For more information, check the easing website, we’ve implemented all the easings available there.

Example:

@Composable
fun MyAnimatedComponent() {
    val value by animateFloatAsState(
        initialValue = 0f,
        targetValue = 1f,
        animationSpec = infiniteRepeatable(
            animation = tween(
                durationMillis = 1500,
                easing = EaseInCirc, // Change the easing here
            ),
        )
    )

    // Use your animated value
}
